Odes Parts : UTV : X4-800 (2019 & Newer)
REAR SUSPENSION
| Ref# | Part | Price | Qty |
|---|---|---|---|
| 1 |
Shock Absorber, Rear (Blue) |
$207.55 | |
| 2 |
Hex Bolt 12x70x1.25 |
$2.39 | |
| 3 |
Hex Locking Nut 12X1.25 |
$2.39 | |
| 4 |
Sway Bar |
$46.59 | |
| 5 |
Cusion, Sway Bar Fixation |
$2.39 | |
| 6 |
Fixation, Sway Bar |
$5.39 | |
| 7 |
Bolt M8x20 |
$2.39 | |
| 8 |
Link Rod, Sway Bar, Driver |
$15.29 | |
| 9 |
Link Rod, Sway Bar, Passenger |
$21.23 | |
| 10 |
Locking Nut 10x1.25 |
$2.39 | |
| 11 |
Rear Upper A-Arm, Driver (Black) |
$43.61 | |
| 12 |
Rear Upper A-Arm, Passenger (Black) |
$43.61 | |
| 13 |
Rear Lower A-Arm, Driver (Black) |
$61.31 | |
| 14 |
Rear Lower A-Arm, Passenger (Black) |
$61.31 | |
| 15 |
A-Arm Inner Sleeve |
$6.45 | |
| 16 |
A-Arm Nylon Sleeve |
$2.39 | |
| 17 |
Grease Zerk (White) |
$5.65 | |
| 18 |
A-Arm Nylon Sleeve Retainer |
$2.39 | |
| 19 |
Hex Flange Bolt 12X75X1.25 |
$4.31 | |
| 20 |
Hex Locking Nut 10X1.25 |
$5.65 | |
| 21 |
Knuckle Assy, Driver |
$209.15 | |
| 22 |
Knuckle Assy, Passenger |
$120.39 | |
| 23 |
Knuckle, Driver |
$101.67 | |
| 24 |
Knuckle, Passenger |
$101.67 | |
| 25 |
Knuckle Bushing |
$7.53 | |
| 26 |
Bearing 6206 (double sealed) |
$27.08 | |
| 27 |
Oil Seal 42X62X7 |
$8.75 | |
| 28 |
Oil Seal 38X62X8 |
$8.75 | |
| 29 |
Knuckle Bushing |
$10.50 | |
| 30 |
Knuckle Fixation Sleeve |
$10.50 | |
| 31 |
Grease Zerk (45 Degrees) |
$2.39 | |
| 32 |
Grease Zerk (90 Degrees) |
$2.39 | |
| 33 |
Oil Seal, Knuckle |
$7.00 | |
| 34 |
Bolt 10x110x1.25 |
$4.31 |
